DEN DF-SPR70 Self-Piercing Riveter 10T

The Sepf-Piercing Riveter 10T DF-SPR70 is part of most OEM recommended methods for joining aluminum panels together. The cold forming technique requires no heat and no pre-drilled holes. The user can manually adjust the actuator speed as well as rivet pressure according to the metal used in order to avoid panel distrotion. Rivet aluminum panels (up to 6.5mm with included rivets but up to 9mm with longer optional rivets) together with high dynamic strength. A pressure gauge on the unit illustrates current pressure amount for controlled operation.

10 Tons - High pressure SPR capable of handling heavy duty installs
PRESSURE CONTROL -; Adjustable dial with an easy to read gauge for ultimate control
ARM SWIVELS 360 degrees - C-ARM swings around into multiple positions for maximum access flexibility
ERGONOMIC HANDLE -; Comfortable operation and stability
MAGNETICC DIE -; Makes rivet positioning effortless and simple

Max Pressure - 10 Tons
Body Weight - 8.8 lbs.
Arm Weight - 6.6 lbs.
Cycle Time - 4 Seconds
Hydraulic System - Closed
INCLUDES: matrices (3mm SPR, 5mm SPR, Extracting, Flow Form, 6.5mm Hole Punch), 2 matrix keys, center punch, strap, HR110 arm, sample box of a variety of steel punch rivets and a carrying case - 1 year warranty
